OSRAM 64744 230V 1000W GX9.5 SHOWBIZ HALOGEN LAMP

Datasheet

Description:

Lead time  3-4 day upon order confirmation

Product information:                                                                                                      ----  -Order reference 64744

Electrical data:
-Nominal wattage 1000.00 W
-Nominal voltage 230 V
-On-mode power 1020.00 W
-Energy consumption in on-mode 1020.0 kWh/1000h

Photometrical data:
-Color rendering index Ra 100
-Φuse value refers to luminous flux .. 360
-Correlated color temperature CCT 3014 K
-Useful luminous flux (Φuse) 20350 lm
-Chromaticity coordinate x 0.430
-Chromaticity coordinate y 0.403

Dimensions & weight:                                                                                                            - Diameter 26.0 mm
-Length 110.0 mm
-Light center length (LCL) 55.0 mm
-Illuminated field 13.0*15.0 mm²
-Filament diameter 15.0 mm

Lifespan:
-Lifespan 750 h

Additional product data:
-Base (standard designation) GX9.5
-Lighting technology used HL

Capabilities:
-Burning position s90

Certificates & standards:
-Energy efficiency class G
