Tomar 240VAC, 50/60Hz, AC STROBE WITH 10" LEADS, UL LISTED Blue MULTI STROBE BEACON

Medium-Profile, Double or Quad-Flash
240VAC, 50/60Hz, AC STROBE WITH 10" LEADS, UL LISTED
OPERATING TEMP: -40C TO 65C
COLOR: BLUE

OTHER INFO:
TOMAR MODEL: 824-240 IS UL LISTED INDUSTRIAL-GRADE SAFETY BEACON DESIGNED FOR HARSH ENVIRONMENT
CONDITION INCLUDING:
- OPERATING TEMPERATURE RANGE OF -40C TO 65C
- HIGH-INTENSITY MULTI-STROBE OUTPUT (DOUBLE/QUAD FLASH)
- CONTINUOUS-DUTY PERFORMANCE FOR TUNNEL & ROADWAY SAFETY APPLICATIONS
- PROVEN RELIABILITY IN INFRASTRUCTURE AND INDUSTRIAL WARNING SYSTEM
THIS ENSURES COMPLIANCE WITH SAFETY VISIBILITY REQUIREMENTS TYPICALLY SPECIFIED IN TUNNEL AND
CIVIL ENGINEERING PROJECTS.

The model 824 family is a medium profile, multi-flash strobe light which can be changed by the customer from double flash to quad flash operation. It features universal
mounting, full size 360° Lexan® lens, high efficiency regulated solid state power supply, and heavy duty xenon strobe lamp. DC units have polarity protection and built-
in filters to protect against radio interference and spike voltages. AC units are designed to withstand multiple line transient spikes of 6000V without damage. The model
824 strobe features a fully potted, Lexan®, multi-purpose mounting base which is vibration and water resistant, and has a plug-in strobe lamp and photocell which can
be activated to automatically reduce intensity during nighttime operation

Model No. Description

BKT Mounting bracket
/LBO–MAXI Lens blackout segment 180º
800/1250–DC Clear lens dust cover
G800 Heavy duty guard
TBO–MAXI Top lens blackout
800–FLG Chrome flange mounting ring ( standard on DC versions,
optional on AC versions )

Model No. Description

4001 Xenon strobe lamp
1700 Color lens ( please specify color )
824–110–BASE 120VAC power supply
824LC–BASE 120VAC power supply with AC cord set
824–240–BASE 208/240VAC power supply
824–1228–BASE 12-28VDC power supply
824MB–BASE 12-28VDC power supply with magnetic mount and coil cord
824MB–SCBASE 12-28VDC power supply with magnetic mount and straight cord
