Osram NAV-E-E40 Europe

Osram NAV-E-E40 Europe

SKU 4050300015644

$ 122.20 SGD
$ 130.75 SGD $ 122.20 SGD
Sale Sold out
Shipping calculated at checkout.

Low stock: 1 left
Request For Quote

Electrical data

Nominal wattage 1000.00 W
Rated wattage 1000.00 W
Lamp current 10.3 A
Nominal voltage 110 V
Ignition voltage
3.6 / 5.0 kVp

Photometrical data

Rated lamp efficacy (standard condition) 128 lm/W
Rated luminous flux 130000 lm
Color rendering index Ra ≤25
Color temperature 2000 K
Rated LLMF at 2,000 h 0.98
Rated LLMF at 4,000 h 0.95
Rated LLMF at 6,000 h 0.93
Rated LLMF at 8,000 h 0.91
Rated LLMF at 12,000 h 0.86
Rated LLMF at 16,000 h 0.80
Rated LLMF at 20,000 h 0.70
Luminous flux 130000 lm

Dimensions & weight

Diameter 165.0 mm
Length 355.0 mm
Product weight 365.30 g

Temperatures & operating conditions

Maximum permitted outer bulb temperature 400 °C
Maximum permitted base edge temperature 250 °C

Lifespan

Rated lamp survival factor at 2,000 h 0.99
Rated lamp survival factor at 4,000 h 0.98
Rated lamp survival factor at 6,000 h 0.96
Rated lamp survival factor at 8,000 h 0.93
Rated lamp survival factor at 12,000 h 0.86
Rated lamp survival factor at 16,000 h 0.74
Rated lamp survival factor at 20,000 h 0.50
Lifespan B50 20000 h
Lifespan B10 10000 h
Lifespan B5 7000 h

Additional product data

Base (standard designation) E40
Product remark ErP compliant according to EU Regulation 245/2009
Design / version Coated
Mercury content 39.0 mg

Capabilities

Dimmable Yes
Burning position Any
Enclosed luminaire required No

Certificates & standards

Energy efficiency class A+
Energy efficiency class A+
Energy consumption 1100 kWh/1000h

Country-specific categorizations

ILCOS SE-1000-H/E/SL-E40-165/355
