MK Electric White 10A Flush Mount Rocker Light Switch x12Pcs
MK Electric White 10A Flush Mount Rocker Light Switch x12Pcs
SKU SKU:4730890
13 in stock
Couldn't load pickup availability
Share
Technical data sheets
*Check stock before ordering. Lead time 4 working days.*
2 Gang: Lead time 1 week.*
3 Gang: Lead time 1 week.*
Product Details
Flush Mount Plateswitches
10 AMP Flush Plateswitch - K4875
6 GANG SP TWO-WAY
Flush:
1, 2 & 3 gang: 3995 ZIC
4 & 6 gang: 862 ZIC
Surface:
1, 2 & 3 gang: K2160 WHI
4 & 6 gang: K2161 WHI
These switches do not have to be derated when used with fluorescent or inductive loads.
K4871, K4872, K4873,
K4874, K4879
These switches can be wired as either one-way or two-way.
Dimensions:
1, 2 & 3 gang: 86 x 86mm
4 & 6 gang: 86 x 146mm
FIXING CENTRES:
1, 2 & 3 gang: 60.3mm
4 & 6 gang: 120.6mm
Standards
BS3676 Pt.1 : 1989
MK Logic Plus Flush Mounting
Stylish, quality, reliable and safe products that incorporate a host of design features which make the installers job easier and quicker. Logic Plus products are made from a high grade thermoset material which has an inherent antimicrobial property. In recent independent tests, the Logic Plus products were equal to, or exceeded, competitor ’Anti-Bac’ products when tested for resistance to MRSA, E-Coli, Salmonella and Klebsiella Pneumoniae.
Specifications
1 Gang
| Attribute | Value |
| Switch Type | Rocker |
| Number of Gangs | 1 |
| Number of Poles | 1 |
| Number of Ways | 2 |
| Mount Type | Flush |
| Current Rating | 10 A |
| IP Rating | IP2X |
| Colour | White |
| Material | Urea Formaldehyde |
| Series | Logic Plus |
| Voltage Rating | 250 V ac |
| Finish | Semi Gloss |
| Illumination | Not Illuminated |
| Faceplate Fixing | Screwed |
| Minimum Box Depth | 16mm |
| Faceplate Depth | 7 mm |
| Colour Shade | MK White |
| Termination Type | Captive Screw |
| Height | 86mm |
| Width | 86 mm |
| Fixing Standard | BS Standard |
| Length | 86 mm |
2 Gang
| Attribute | Value |
| Switch Type | Rocker |
| Number of Gangs | 2 |
| Number of Poles | 1 |
| Number of Ways | 2 |
| Mount Type | Flush |
| Current Rating | 10 A |
| IP Rating | IP2X |
| Colour | White |
| Material | Urea Formaldehyde |
| Series | Logic Plus |
| Voltage Rating | 250 V ac |
| Finish | Semi Gloss |
| Illumination | Not Illuminated |
| Faceplate Fixing | Screwed |
| Faceplate Depth | 7 mm |
| Height | 86mm |
| Width | 86 mm |
| Depth | 12 mm |
| Fixing Standard | BS Standard |
| Colour Shade | MK White |
| Length | 86 mm |
| Termination Type | Captive Screw |
| Minimum Box Depth | 16mm |
3 Gang
| Attribute | Value |
| Switch Type | Rocker |
| Number of Gangs | 3 |
| Number of Poles | 1 |
| Number of Ways | 2 |
| Mount Type | Flush |
| Current Rating | 10 A |
| IP Rating | IP2X |
| Colour | White |
| Material | Urea Formaldehyde |
| Series | Logic Plus |
| Voltage Rating | 250 V ac |
| Finish | Semi Gloss |
| Illumination | Not Illuminated |
| Faceplate Fixing | Screwed |
| Height | 86mm |
| Colour Shade | MK White |
| Length | 86 mm |
| Minimum Box Depth | 16mm |
| Termination Type | Captive Screw |
| Width | 86 mm |
| Faceplate Depth | 7 mm |
| Fixing Standard | BS Standard |
