Eaton IP66 Cable Mount 2P + E Power Connector Socket ATEX, Rated At 16A, 250 V

Technical data

Ex-plugs and receptacles acc. to IEC 60309-1/2 16A
Marking accd. to 2014/34/EU Wall socket, plug, coupler:
Flange socket:
II 2G / Ex db eb [ia] IIC / IIB+H2 T6
II 2 D Ex IIIC / IIIB T80 Db
II 2G Ex db eb IIC / IIB+H2 Gb
II 2 D Ex tb IIIC Db
EC-Type Examination Certifi cate Wall socket, plug, coupler:
 Flange socket:
BVS 17 ATEX E 053 X
BVS 15 ATEX E 101 U
IECEx Certifi cate of Conformity Wall socket, plug, coupler:
Flange socket:
IECEX BVS 17.0045X
IECEX BVS 15.0088U
EAC (TR) 1EX D E [IA] IIC/IIB T6 GB X
EX TB IIIC T80°C DB X
Permissible ambient temperature -55 °C to + 55 °C
Rated voltage up to 415 V, (3-pole) / 690 V, (4-pole) / 690 V, (5-pole) AC
Rated current 16 A
Frequency up to 400 Hz
Rated making / Rated breaking capacity AC-3
accd. EN 60947-3
Ue 250 V / Ie 16 A (3-pole)
Ue 690 V / Ie 16 A (4-pole)
Ue 500 V / Ie 16 A (5-pole)
External back-up fuse, max. without therm. protection: 16 A
with therm. protection: 35 A gG (rated current 16 A set to)
Protection class I
Degree of protection accd. to EN 60529 IP66
Enclosure colour black
Wall socket
Cable entry 1 x M25 cable gland, 1 x M25 plastic Ex-screw plug or
2 x metal thread M20 with plastic Ex-screw plug
