High Bay 40W 5700K Product Details
The Eaton Crouse-Hinds HPLN-5L-C3-W is a high-performance LED high bay luminaire designed for Zone 1 & Zone 2 hazardous environments. With 40W power consumption and 5700K cool white output, it delivers powerful, uniform illumination ideal for industrial and explosive atmospheres.
This model includes a trunnion mounting bracket, enabling adjustable installation for precise light direction in high bay and mid bay applications. The HPLN series is engineered with high-efficacy LED technology (up to ~130 lm/W), delivering excellent brightness while reducing energy consumption.
Built with a copper-free aluminum housing and tempered glass lens, it ensures durability, corrosion resistance, and long service life even in harsh industrial environments.
High Bay 40W 5700K Key Features
- 40W high-efficiency LED luminaire
- 5700K cool white light (CW)
- Approx. 5323 lumens output
- High efficacy ~130 lm/W
- Includes trunnion mount (adjustable bracket)
- Suitable for Zone 1 & Zone 2 hazardous areas
- Wide beam angle 120° (W type)
- IP66 rated for dust & water protection
- High surge protection (~4kV)
- Maintenance-free long-life design
- Multiple mounting options available (ceiling, wall, pendant, trunnion)
Benefits
- Safe lighting in explosive & hazardous zones
- Energy savings vs 100–150W HID lamps
- Adjustable trunnion mounting for directional lighting
- Long lifespan reduces maintenance cost
- Reliable in extreme environments (-40°C to +55°C)
- High brightness improves workplace safety & visibility
Applications
- Oil & gas refineries
- Petrochemical plants
- Offshore platforms
- Warehouses & high bay industrial areas
- Tunnels & loading docks
- Chemical & pharmaceutical industries
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Eaton (Crouse-Hinds Series) |
| Model | HPLN-5L-C3-W |
| Type | LED Hazardous Area High Bay |
| Wattage | 40W |
| Luminous Flux | ~5323 lm |
| Color Temperature | 5700K (Cool White) |
| Beam Angle | Wide (120°) |
| Voltage | 100–240V AC / 127–250V DC |
| Frequency | 50/60 Hz |
| Power Factor | >0.95 |
| Efficacy | ~130 lm/W |
| Equivalent | 100–150W HID |
| IP Rating | IP66 |
| Housing | Copper-free aluminum |
| Lens | Tempered glass |
| Mounting | Trunnion (Included) |
| Operating Temp | -40°C to +55°C |
| Hazardous Rating | Zone 1 & Zone 2 |
| Certifications | IECEx / ATEX |
