SUBENT Forward Throw LED Wall Pack

Technical Details

Datasheet

Luminaire for external walls and columns for lighting the outside of buildings.

Forward throw optics semi-cut-off beam provides excellent coverage and reduced glare.

Full diecast aluminum housing with highly efficient led modules

Dimmable by 0-10V DC or set required wattage from 45W down to 20W by a selection of Reset resistor.

Model No.: SWL C45HU30K

Fixture Color: Matt black

LED: High-performance SMD LEDs

Wattage: 45W

Color Temperature: 3000K

Dimension               : 320 x 225 x Projection 210mm

Luminaire Lumens: 3024lm

Driver: Integrated HPF driver

Dimming: Dimmable by 0-10V DC signal.

Note: Wattage can be set at 20W, 25W, 30W, 35W, 40W by Rset
