PHILIPS Master MHN-LA
PHILIPS Master MHN-LA
SKU SKU:928072205130
Regular price
$ 666.22 SGD
Regular price
$ 712.85 SGD
Sale price
$ 666.22 SGD
Unit price
/
per
Shipping calculated at checkout.
Low stock: 1 left
Couldn't load pickup availability
Share
General Information
Light Technical
Operating and Electrical
Controls and Dimming
Mechanical and Housing
Approval and Application
UV
Luminaire Design Requirements
| Cap-Base |
X528 [ X528]
|
| Operating Position |
P5 [ Parallel +/-5D or Horizontal(HOR)]
|
| Life to 5% Failures (Nom) |
6000 h
|
| Life to 10% Failures (Nom) |
8000 h
|
| Life to 20% Failures (Nom) |
10000 h
|
| Life to 50% Failures (Nom) |
15000 h
|
| Color Code |
956 [ CCT of 5600K]/842[CCT of 4200K]
|
| Luminous Flux (Rated) (Min) |
82000 lm / 170000 lm / 193000 lm
|
| Luminous Flux (Rated) (Nom) |
87000 lm / 190000 lm / 214000 lm
|
| Color Designation |
Daylight
|
| Lumen Maintenance 1000 h (Nom) |
90 %
|
| Lumen Maintenance 2000 h (Nom) |
80 %
|
| Chromaticity Coordinate X (Nom) |
337
|
| Chromaticity Coordinate Y (Nom) |
331
|
| Correlated Color Temperature (Nom) |
5600 K
|
| Luminous Efficacy (rated) (Nom) |
86.0 lm/W
|
| Color Rendering Index (Nom) |
80
|
| Lamp supply voltage |
230 V [ 230]
|
| Power (Rated) (Nom) |
1000.0 W / 2000 W
|
| Lamp Current Run-Up (Max) |
15 A
|
| Lamp Current (EM) (Nom) |
9.3 A
|
| Ignition Supply Voltage (Min) |
198 V
|
| Voltage (Max) |
140 V
|
| Voltage (Min) |
110 V
|
| Voltage (Nom) |
125 V
|
| Dimmable |
No
|
| Bulb Finish |
Clear
|
| Cap-Base Information |
Cable
|
| Energy Efficiency Label (EEL) |
A+
|
| Mercury (Hg) Content (Nom) |
95 mg
|
| Energy Consumption kWh/1000 h |
1144 kWh
|
| Specific Eff. Radiant Power |
270 mW/klm
|
| Bulb Temperature (Max) |
920 °C
|
| Pinch Temperature (Max) |
350 °C
|
