KGP LED RC Series Constant Current Driver

KGP LED RC Series Constant Current Driver

SKU SKU:RC10W300

Regular price $ 28.00 SGD
Regular price $ 30.00 SGD Sale price $ 28.00 SGD
Sale Sold out
Shipping calculated at checkout.
Power
Current

Request For Quote

Technical Details

Datasheet

1. Parameters
category Item Technical Norm
Features
Output Type Constant Current
IP Grade IP44
Insulation Class ClassⅡ
Input
Rated Input Voltage 220-240VAC
Range of Input Voltage 198-264VAC
Frequency 50/60Hz
Input Current ≤0.07A (198VAC,full load)
Input Power ≤ 13.5W (230VAC,full load)
Power Factor ≥0.9 (230VAC,full load)
THD ≤15% (230VAC,full load)
No-load Power Consumption ≤0.5W @230VAC
Inrush Current ≤5A/350us (230VAC, Full-load)
Connected quantity of 16A Breaker 30pcs/type B ; 48pcs/type C @ 230Vac
Output
Current Accuracy ±8%(150mA) ±7.5%(250mA)
±6%(250mA,300mA,350mA)
±5%(400mA,450mA,500mA,600mA,
650mA,700mA)
Max. Output Power 10.5W
Started Delay Time ≤0.5S (230VAC,full load)
Current Ripple ±5%(Imax-Imin)/(Imax+Imin)
Protection
Short Circuit Protection Auto Recovery
Overload Protection Auto Recovery
No-load Protection Auto Recovery
Insulation voltage I/P to O/P , 3KVac/1min
Insulation resistance >100M ohm @ 500VDC
Leakage current I/P to O/P < 250μA
Environment
Ta/Operation Temperature -20….+60℃
Ts/Storage Temperature -25….+85℃
Tc/Enclosure Temperature 90 ℃
Humidity 10%....90%RH
Atmosphere 86-108KPa
Construction
Connection Method Direct Lead
Installation Build-in
PRI Wire preparation 0.5-1.5□
SEC Wire preparation 0.5-1.5□
Dimension Ф42.3*20.2mm (R*H)
Standards
Certification TUV、CE、SAA
Safety Standards EN61347-1:2015,EN61347-2-13:2014/A1:2017,E
N62493:2015, AS/NZS IEC61347.2.13:2013,
AS/NZS 61347.1:2016
EMC Standards EN55015:2013/A1:2015,EN61000-3-2:2014,EN61
000-3-3:2013,EN61547:2009
Performance EN62384
Surge L-N/2KV
Others
RoHS complied to 2011/65/EU
Life Time 50,000h @50℃(Ta)/ @90℃(Tc)
Warranty 1years , F.R. < 10000ppm
