ABB M2BA 250 SMB-4 DNV 3-Phase Electric Motor 88kW

ABB M2BA 250 SMB-4 DNV 3-Phase Electric Motor 88kW

m2ba-250-smb-4-dnv

$ 11,020.00 SGD
$ 11,020.00 SGD
Sale Sold out
Shipping calculated at checkout.

Request For Quote

The ABB M2BA 250 SMB-4 DNV 3-Phase Electric Motor is engineered for reliable performance in demanding industrial applications. Because of its 88kW power output and robust construction, it delivers consistent operation for main air compressor systems.

Moreover, the motor operates at 440V and 60Hz, which ensures stable electrical performance. In addition, its S1 continuous duty rating allows uninterrupted operation, making it ideal for heavy-duty industrial environments.

Furthermore, the motor features a 4-pole design with 1800 RPM speed, thereby providing efficient power transmission. As a result, it maintains optimal performance with reduced energy losses. Therefore, it is suitable for industries requiring dependable and long-lasting motor solutions.

On the other hand, the DNV certification ensures compliance with marine and industrial standards. Overall, the ABB M2BA motor combines durability, efficiency, and reliability for critical applications.

  • 88kW high-performance 3-phase motor
  • Designed for main air compressor applications
  • S1 continuous duty for uninterrupted operation
  • 1800 RPM (4-pole) efficient performance
  • DNV certified for industrial and marine standards
  • High power factor (0.87) for energy efficiency
  • Robust and durable construction
  • IEC 34-1 compliant design

Technical Specifications

Parameter Details
Brand ABB
Product Type 3-Phase Induction Motor
Series M2BA
Model M2BA 250 SMB-4
Application Main Air Compressor
Duty Type S1 (Continuous Duty)
Certification DNV
Standard IEC 34-1
Product Code 2GBA 252220-ADD
Serial/Ref No. CS L01-000201

Electrical Specifications

Parameter Details
Voltage 440 V
Frequency 60 Hz
Power 88 kW
Speed 1800 RPM
Current 139 A
Power Factor (Cos φ) 0.87
Phase 3 Phase

Mechanical / Connection Details

Parameter Details
Frame Size 250
Mounting Type SMB
Number of Poles 4 Pole
Terminal Connection One or Two M12 Connections / Cable Entry
Additional Code 437+09+25+451
At the top of Smile, a LED shows the current status as: green = protection OK, red = this emergency stop has been pressed and if the LED is off, an emergency stop earlier in the loop has been actuated. Smile is also available with black push button and is used as a safety stop. See section on safety stops. Smile small and cost effective E-stop Smile emergency stop has six different variants: 1. Smile 10EA has a 1 m cable connected through the base of the unit. 2. Smile 10EK has four 1 m short connecting leads through the base of the unit.
Parameter Details
Brand ABB Schweiz AG
Data Sheet & Drawings M2BA 250 SMB-4 DNV
Weight 185 kg
Country of Manufacture Switzerland
