LF 80B metallic shaft : DATASHEET

Metallic shaft coupling of cooling fanType: LF 80B Motor Type:M2BA315SMA4

Shaft Coupling (Cooling Fan)

• Type: LF 80B
• Material/Part: Metallic shaft coupling
• Used in: Cooling fan of motor

This is a metal connector part that joins the motor shaft to the cooling fan so the fan rotates when the motor runs.

Its job is:

• Transfer rotation from motor → fan
• Keep alignment stable
• Reduce vibration

Motor Details

• Motor Type: M2BA315SMA4
• Brand: ABB ABB

This is a large industrial motor used in heavy-duty machines.
The cooling fan system is attached to it to prevent overheating.

ABB provides industrial power supply systems used in automation and control panels.

What they do:

They convert electrical power into stable DC voltage like:

• 5 V DC
• 12 V DC
• 24 V DC
• 48 V DC

Enclosures:

• Plastic type
• Metal type

Signal Converters (CC Range)

• ABB CC series devices help in signal conversion

ILPH / Data Converters (Communication Units)

What they do:

• Connect machines with different communication standards
• Allow data sharing between old and new systems

Overall Simple Summary

This whole description includes 3 main things:

1. Mechanical part

• Shaft coupling (LF 80B) connects motor to cooling fan

2. Motor system

• ABB M2BA motor runs industrial equipment

3. Electrical & control systems

• Power supplies → give stable DC power
• Signal converters → convert sensor signals
• Data converters → enable communication between systems

“This is an ABB motor system with cooling fan coupling and supporting electronic modules like power supplies and signal converters used for industrial automation and control.”

Brand : ABB B.V. Weight (kg) : 80.000000 Country of Manufacture : Switzerland
