MEAN WELL ELG-240-48A-3Y LED Power Supplies
MEAN WELL ELG-240-48A-3Y LED Power Supplies
SKU:ELG-240-48A-3Y
Tidak dapat memuatkan ketersediaan pengambilan
Kongsi
The MEAN WELL ELG-240-48A-3Y LED Power Supplies is a premium industrial LED driver designed for high-performance LED lighting applications. Delivering up to 240W output power with 48V DC and 5A current, this driver supports both constant voltage and constant current operation, making it suitable for LED strips, flood lights, high bay lights, architectural lighting, and street lighting systems.
Its rugged metal housing with IP65-rated protection ensures reliable operation in harsh indoor and outdoor environments. The “A-Type” design allows output voltage and current adjustment via built-in potentiometers, providing flexible installation and optimized LED performance. Featuring high efficiency up to 93%, active PFC, fanless cooling, and multiple protection functions, the ELG-240-48A-3Y offers long-lasting and energy-efficient performance for professional lighting installations
- 240W high-power LED driver
- 48V DC output with 5A current
- Constant Voltage + Constant Current operation
- Adjustable output voltage and current
- Wide input range: 100–305V AC
- IP65 waterproof metal enclosure
- High efficiency up to 93%
- Built-in active PFC function
- Fanless natural air cooling
- Over-voltage, overload & short-circuit protection
- Suitable for indoor and outdoor installations
- Long operational lifespan with 5-year warranty
- Industrial-grade reliability for commercial lighting systems
| Specification | Details |
|---|---|
| Brand | MEAN WELL |
| Model Number | ELG-240-48A-3Y |
| Product Type | LED Driver / Switching Power Supply |
| Output Power | 240W |
| Output Voltage | 48V DC |
| Output Current | 5A |
| Output Type | Constant Voltage + Constant Current |
| Voltage Adjustment Range | 44.8 ~ 51.2V |
| Current Adjustment Range | 2.5 ~ 5A |
| Input Voltage | 100 ~ 305V AC |
| Input Frequency | 47 ~ 63Hz |
| Efficiency | Up to 93% |
| Power Factor | PF ≥ 0.95 |
| Cooling Method | Fanless Natural Convection |
| Protection Rating | IP65 |
| Housing Material | Metal Enclosure |
| Operating Temperature | -40°C to +90°C |
| Dimensions | 244 × 71 × 37.5 mm |
| Weight | Approx. 1.2kg |
| Protection Features | Short Circuit / Over Voltage / Over Temperature / Overload |
| Mounting Type | Chassis Mount |
| Applications | Street Lights, Flood Lights, |
| High Bay Lights, LED Strips |
