LEDVANCE LVED PRO 42W/220-240/1A CS VS40 G3

The LEDVANCE LVED PRO 42W/220-240/1A CS VS40 G3 is a professional constant-current LED driver designed to provide reliable and efficient power for LED luminaires. With a maximum output power of 42 W and selectable output current up to 1000 mA, it provides flexibility for a variety of indoor commercial and architectural LED lighting applications.

Operating from a rated 220–240 V AC supply, the driver supports an input voltage range of approximately 198–264 V AC at 50/60 Hz. It delivers an output voltage range of 25–42 V DC and achieves efficiency of up to 89% at full load, helping minimize energy losses and heat generation. A high power factor of approximately 0.97 further contributes to efficient electrical performance.

The Current Selector (CS) functionality allows the output current to be configured according to the requirements of the connected LED module, making the driver suitable for multiple luminaire designs and simplifying installation and inventory requirements.

Designed for high-quality LED operation, the LVED PRO G3 features low output-current ripple of less than 5%, helping provide stable and consistent illumination. The driver incorporates SELV galvanic isolation for electrical safety and offers 1 kV L-N surge capability for additional protection against voltage disturbances.

With its IP20 protection rating, the driver is intended primarily for indoor installations or installation inside a suitably protected luminaire or enclosure. Its rated service life of up to 50,000 hours makes it well suited for long-term professional lighting installations.

Key Features

• Maximum output power: 42 W
• Rated input voltage: 220–240 V AC
• Input voltage range: 198–264 V AC
• Frequency: 50/60 Hz
• Output voltage: 25–42 V DC
• Output current: Up to 1000 mA
• Current Selector (CS) for flexible output-current configuration
• Efficiency: Up to 89% at full load
• Power factor: Approx. 0.97 at full load
• THD: ≤10% at full load
• Output current ripple: <5%
• Output current tolerance: ±5%
• Surge protection: 1 kV (L-N)
• Galvanic isolation: SELV
• Protection rating: IP20
• Dimming: Non-dimmable
• Lifetime: Up to 50,000 hours
