ABB M2BAT315SMA6 3-Phase Electric Motor 75kW | 415V

ABB M2BAT315SMA6 3-Phase Electric Motor 75kW | 415V

m2bat315sma6

PDF Datasheet

$ 10,575.00 SGD
$ 10,575.00 SGD
Jualan Habis dijual
Penghantaran dikira semasa pembayaran.

Request For Quote

Delivery

Singapore

1-3 work days ( 90% of Shipments)

For items that are stocked outside Singapore, it takes 7 - 14 work days.

International

7-14 work days.

Pick FEDEX at checkout for reliable and Fast Deliveries.

Taxes

Singapore

GST Not Applicable - Prices displayed are final prices.

International

As per importering country's Duties and taxes. To be paid to Carrier or Customs Dept. Importer is responsible for Import Duty and Taxes.

Lembaran data

cs@delight.com.sg
Tel: +65 6429 8402
Whatsapp: +65 8900 0895

We admit ! For Technical Clarifications, our AI BOT is Quicker than us. Try it !

3-Phase Electric Motor : DATASHEET

ABB M2BAT315SMA6 3-Phase Electric Motor 75kW | 415V | 50Hz Industrial Motor

Motor Information

  • Brand: ABB ABB
  • Motor Type: M2BAT315SMA6
  • Power: 75 kW
  • Voltage: 415 V AC
  • Phase: 3 Phase
  • Current: 143 A
  • Frequency: 50 Hz
  • Speed: 992 RPM
  • Protection Class: IP55 (dust protected + water jets protected)
  • Application: Salt Centrifuge (Rotor duty)

This is a heavy-duty industrial motor used to rotate a salt centrifuge.
It is designed for:

  • Continuous industrial operation
  • High load (75 kW power)
  • Harsh environment (IP55 protection)

What is “RTD / CC-E Module”?

These are temperature signal converter modules used with PT100 temperature sensors.

👉 PT100 = a temperature sensor used in motors/machines to monitor heat.

ABB CC-E RTD Modules (Simplified Table)

These devices convert temperature signals into electrical outputs.

Model Temperature Range Output Type
1SVR011730R2500 0…100°C 0–10 V
1SVR011731R1200 0…100°C 0–20 mA
1SVR011732R1300 0…100°C 4–20 mA
1SVR011733R1400 -50…+50°C 0–10 V
1SVR011734R1500 -50…+50°C 0–20 mA
1SVR011735R1600 -50…+50°C 4–20 mA
1SVR011736R1700 0…300°C 0–10 V
1SVR011737R1000 0…300°C 0–20 mA
1SVR011738R2100 0…300°C 4–20 mA
1SVR011739R2200 0…250°C 0–10 V
1SVR011740R0700 0…250°C 0–20 mA
1SVR011741R2400 0…250°C 4–20 mA

Supply Voltage

  • Input Power: 110–240 V AC (Universal supply)

You have 2 main parts:

1. Motor (ABB 75 kW)

  • Rotates the centrifuge machine

2. Temperature monitoring system (CC-E RTD modules)

  • Reads temperature from motor using PT100 sensor
  • Converts it into signals like:
    • Voltage (0–10V)
    • Current (0–20 mA or 4–20 mA)
  • Motor = “Heart of machine” (makes it rotate)
  • PT100 sensor = “Thermometer of motor”
  • CC-E module = “Translator” (converts temperature into electrical signal for PLC/control system)
Brand : ABB K.K. Weight (kg) : 800.000000 Country of Manufacture : Spain
