Steinel Passive Infrared (PIR), IR Quattro HD(White)

Technical Details:

Datasheet for COM1

Datasheet for COM2

Detection no finer!

HD isn't just restricted to televisions but from now on also used in presence detectors. Because IR Quattro HD provides extremely high-definition detection. 4,800 switching zones and a square detection footprint with a presence zone covering a true 64 m² leave no margin whatsoever for inadvertent triggering and blind spots. Unique: The presence zone can be mechanically scaled without the slightest loss of quality.

IR Quattro HD COM1 is ideal for indoors, ideal for medium to large-size offices, conference and meeting rooms, classrooms and lecture theatres, sports halls and warehouses, installation height up to 10 m, for switching light 'ON' and 'OFF', 4800 switching zones for the ultimate in detection quality, presence detection over a true 64 m2, square detection zone, mechanically scalable.

IR Quattro HD COM2 is ideal for are ideal for indoors, ideal for medium to large-size offices, conference and meeting rooms, classrooms and lecture theatres, sports halls and warehouses, installation height up to 10 m, for switching light as well as HVAC 'ON' and 'OFF', 4800 switching zones for the ultimate in detection quality, presence detection over a true 64 m2, square detection zone, mechanically scalable.

Comes with 5 years Manufacturer Warranty

Technical Specifications:

Type: Passive infrared
Time Setting: 30sec - 30min
Output: 2000W Max
Tangential: 20m x 20m
Presence: 8m x 8m
