| DULUX L 18W/827 2G11 10X1 OSRAM |
| DULUX L 18W/830 2G11 10X1 OSRAM |
| DULUX L 18W/840 2G11 10X1 OSRAM |
| DULUX L 18W/865 2G11 10X1 OSRAM |
| DULUX L 24W/827 2G11 10X1 OSRAM |
| DULUX L 24W/830 2G11 10X1 OSRAM |
| DULUX L 24W/840 2G11 10X1 OSRAM |
| DULUX L 36W/827 2G11 10X1 OSRAM |
| DULUX L 36W/830 2G11 10X1 OSRAM |
| DULUX L 36W/840 2G11 10X1 OSRAM |
| DULUX L 36W/865 2G11 10X1 OSRAM |
| DULUX L 36W/930 2G11 10X1 OSRAM |
| DULUX L 36W/954 2G11 10X1 OSRAM |
| DULUX L 40W/830 2G11 10X1 OSRAM |
| DULUX L 40W/840 2G11 10X1 OSRAM |
| DULUX L 40W/865 2G11 10X1 OSRAM |
| DULUX L 55W/827 2G11 10X1 OSRAM |
| DULUX L 55W/830 2G11 10X1 OSRAM |
| DULUX L 55W/840 2G11 10X1 OSRAM |
| DULUX L 55W/865 2G11 10X1 OSRAM |
| DULUX L 55W/930 2G11 10X1 OSRAM |
| DULUX L 55W/954 2G11 10X1 OSRAM |
| DULUX L 80W/830 2G11 10X1 OSRAM |
|
DULUX L 80W/840 2G11 10X1 OSRAM
Electrical data
| Nominal wattage |
18 W /24 W / 36 W / 40 W / 55 W / 80 W |
| Nominal voltage |
57 V |
| Rated wattage |
18.00 W |
Photometrical data
| Nominal luminous flux |
1200 lm |
| Light color (designation) |
LUMILUX INTERNA |
| Luminous flux at 25 °C |
1200 lm |
| Rated luminous flux |
1200 lm |
| Rated color temperature |
2700 K |
| Color rendering index Ra |
≥80 / 90 |
| Rated LLMF at 4,000 h |
0.86 |
| Rated LLMF at 6,000 h |
0.82 |
| Rated LLMF at 8,000 h |
0.80 |
| Rated LLMF at 12,000 h |
0.76 |
| Rated LLMF at 16,000 h |
0.81 |
| Rated LLMF at 20,000 h |
0.80 |
| Luminance |
2.1 cd/cm² |
Dimensions & weight
| Diameter |
17.5 mm |
| Overall length |
214.5 mm |
| Tube diameter |
17.5 mm |
| Length |
217.0 mm |
| Length acc. to IEC standard |
225 mm |
| Length with base excl. base pins/connection |
217.00 mm |
| Outer bulb |
T16 |
| Maximum diameter |
17.0 mm |
Temperatures & operating conditions
| Rated ambient temp.w.max.luminous flux |
25.0 °C |
Lifespan
| Nominal lamp life time |
12000 h |
| Rated lamp life time |
12000 h |
| Service life |
13000 h
|
| Rated lamp survival factor at 2,000 h |
0.99 |
| Rated lamp survival factor at 4,000 h |
0.99 |
| Rated lamp survival factor at 6,000 h |
0.98 |
| Rated lamp survival factor at 8,000 h |
0.92 |
| Rated lamp survival factor at 12,000 h |
0.50 |
| Rated lamp survival factor at 16,000 h |
0.81 |
| Rated lamp survival factor at 20,000 h |
0.50 |
| Operation mode LLMF/LSF |
HF |
| Lifespan |
20000 h
|
Additional product data
| Base (standard designation) |
2G11 |
| Mercury content |
2.3 mg |
| Product remark |
For ECG and CCG operation |
Capabilities
| Dimmable |
Yes |
| Suitable for indoor |
Yes |
Certificates & standards
| Energy efficiency class |
A |
| Energy consumption |
20 kWh/1000h |
Country-specific categorizations
| ILCOS |
FSD-18/827-E-2G11-43,9/217 |
|
