Moflash LED100 LED Beacon, Flashing, Surface Mount
Moflash LED100 LED Beacon, Flashing, Surface Mount
SKU SKU:LED100-01-01-8-20V
สต็อกสินค้าเหลือน้อย: เหลือ 3 ชิ้น
ไม่สามารถโหลดความพร้อมในการรับสินค้าด้วยตนเองได้
แบ่งปัน
Product Details
Moflash Industrial ECO LED Beacons - LED100 Series
The LED100 economy series is suitable for light commercial & industrial signalling applications where local indication is required. These beacons have two selectable stages of alarm, flashing or continuous (static) mode, selectable by a jumper link on the PCB. The design also allows for a third wire connection giving flexibility to switch from a pre-set static mode to flashing.
The ECO LED beacons have been designed predominantly to offer a cost effective solution against more traditional incandescent types of lamps, whether through new plant and machinery installations or existing facility upgrades.
The design allows for termination inside the enclosure through the base.
Dual function, flashing or continuous (static) mode
Continuously rated
LED long life
Low current consumption
Suitable for surface, conduit box or wall mounting
Optional wall bracket & guard available
2 point fixing
360° light output around the vertical axis
Dustproof and weatherproof
UV stable polycarbonate lens
UV stable ABS plastic base
160 flashes per minute (FPM)
IP65 protection
RoHS compliant
CE marked
8 → 20 V ac/dc, Amber
| Attribute | Value |
|---|---|
| Supply Voltage | 8 → 20 V ac/dc |
| Light Effect | Flashing |
| Lens Colour | Amber |
| Mounting Style | Surface Mount |
| Bulb Type | LED |
| Current Type | AC, DC |
| Base Diameter | 72mm |
| Housing Colour | Black |
| Lamp Included | Yes |
| Series | LED100 |
| Multifunction | Yes |
| Height | 107mm |
| Base Length | 33mm |
| IP Rating | IP65 |
8 → 20 V ac/dc, Red
| Attribute | Value |
|---|---|
| Supply Voltage | 8 → 20 V ac/dc |
| Light Effect | Flashing |
| Lens Colour | Red |
| Mounting Style | Surface Mount |
| Bulb Type | LED |
| Current Type | AC, DC |
| Base Diameter | 72mm |
| Housing Colour | Black |
| Lamp Included | Yes |
| Series | LED100 |
| Multifunction | Yes |
| Height | 107mm |
| Base Length | 33mm |
| IP Rating | IP65 |
| Attribute | Value |
|---|---|
| Supply Voltage | 20 → 30 V |
| Light Effect | Flashing, Static |
| Lens Colour | Red |
| Mounting Style | Surface Mount, Wall Mount |
| Bulb Type | LED |
| Current Type | AC, DC |
| Current Consumption | 110mA |
| Base Diameter | 72mm |
| Housing Colour | Black |
| Lamp Included | Yes |
| Series | LED100 |
| Multifunction | Yes |
| Height | 107mm |
| IP Rating | IP65 |
| Base Length | 33mm |
20 → 30 V ac/dc, Amber
| Attribute | Value |
|---|---|
| Supply Voltage | 20 → 30 V ac/dc |
| Light Effect | Flashing |
| Lens Colour | Amber |
| Mounting Style | Surface Mount |
| Bulb Type | LED |
| Current Type | AC, DC |
| Current Consumption | 110mA |
| Base Diameter | 72mm |
| Housing Colour | Black |
| Lamp Included | Yes |
| Series | LED100 |
| Multifunction | Yes |
| Height | 107mm |
| Base Length | 33mm |
| IP Rating | IP65 |
20 → 30 V ac/dc, Green
| Attribute | Value |
|---|---|
| Supply Voltage | 20 → 30 V ac/dc |
| Light Effect | Flashing |
| Lens Colour | Green |
| Mounting Style | Surface Mount |
| Bulb Type | LED |
| Current Type | AC, DC |
| Base Diameter | 72mm |
| Housing Colour | Black |
| Lamp Included | Yes |
| Series | LED100 |
| Multifunction | Yes |
| Height | 107mm |
| IP Rating | IP65 |
| Base Length | 33mm |
40 → 380 V dc, 85 → 285 V ac, Green
| Attribute | Value |
|---|---|
| Supply Voltage | 40 → 380 V dc, 85 → 285 V ac |
| Light Effect | Flashing |
| Lens Colour | Green |
| Mounting Style | Surface Mount |
| Bulb Type | LED |
| Current Type | AC, DC |
| Base Diameter | 72mm |
| Housing Colour | Black |
| Lamp Included | Yes |
| Series | LED100 |
| Multifunction | Yes |
| Height | 107mm |
| Base Length | 33mm |
| IP Rating | IP65 |
40 → 380 V dc, 85 → 285 V ac, Red
| Attribute | Value |
|---|---|
| Supply Voltage | 40 → 380 V dc, 85 → 285 V ac |
| Light Effect | Flashing |
| Lens Colour | Red |
| Mounting Style | Surface Mount |
| Bulb Type | LED |
| Current Consumption | 35mA |
| Current Type | AC, DC |
| Base Diameter | 72mm |
| Housing Colour | Black |
| Lamp Included | Yes |
| Series | LED100 |
| Multifunction | Yes |
| Height | 107mm |
| IP Rating | IP65 |
| Base Length | 33mm |
85 → 280 V ac, 85 → 380 V dc, Amber
| Attribute | Value |
|---|---|
| Supply Voltage | 85 → 280 V ac, 85 → 380 V dc |
| Light Effect | Flashing |
| Lens Colour | Amber |
| Mounting Style | Surface Mount, Wall Mount |
| Bulb Type | LED |
| Current Type | AC, DC |
| Current Consumption | 35mA |
| Base Diameter | 72mm |
| Housing Colour | Black |
| Lamp Included | Yes |
| Series | LED100 |
| Multifunction | Yes |
| Height | 107mm |
| Base Length | 33mm |
| IP Rating | IP65 |
