LCD-405-6500K-LED Marine
LCD-405-6500K-LED Marine
SKU:LCD-FA-405-6500K-LN90
ไม่สามารถโหลดความพร้อมในการรับสินค้าด้วยตนเองได้
Delivery
Delivery
Singapore
1-3 work days ( 90% of Shipments)
For items that are stocked outside Singapore, it takes 7 - 14 work days.
International
7-14 work days.
Pick FEDEX at checkout for reliable and Fast Deliveries.
Taxes
Taxes
Singapore
GST Not Applicable - Prices displayed are final prices.
International
As per importering country's Duties and taxes. To be paid to Carrier or Customs Dept. Importer is responsible for Import Duty and Taxes.
แผ่นข้อมูล
แผ่นข้อมูล
cs@delight.com.sg
Tel: +65 6429 8402
Whatsapp: +65 8900 0895
We admit ! For Technical Clarifications, our AI BOT is Quicker than us. Try it !
แบ่งปัน
LED Chip ：SMD 5050 lenses beam angel 30°
CCT: 6500K Lumen output：150-160lm/W
Voltage：90-305VAC / 50/60Hz
Stainless steel # front cover with grid net & bracke/marine anti-salt water coating paint
| Specifiction | data | parameter |
| Power | 400W | |
| Initial luminous flux @4000K |
64,000lm | |
| Initial LED luminaire efficacy | 160lm/W | |
| CRI | ≥70 | |
| Calculated Lumen Maintenance（L79，TM-21@25℃） | ＞100000hours | |
| Color Temperature | 3000/4000/5000K | |
| Distribution | sports/area | |
| Light Distribution Component | polycarbonate microlens optic / PC cover 4mm / stainless steel front 2mm | |
| Light source | anti-high temperature +120℃ LEDs SMD5050/5W/pcs | |
| LED quantity | SMD5050 144 pcs | |
| Input Voltage | AC100-277V 50/60Hz | |
| Driver | CE RoHs SAA UL TUV cUL approved driver | |
| THD | ＜20% | |
| Power Factor | ＞96% | |
| Power-supply Efficiency | ＞90% | |
| Housing | Aluminum Alloy die-casted / stainless steel front | |
| Weight | 13kg | |
| Lens | reflector(Polycarbonate lens for 30deg / 60 deg /9deg etc on requests) | |
| Fixation material bracket | (Stainless steel ) | |
| Anti-UV PC plastic | PC cover 4mm | |
| Finish | 2 layers Mirane grade anti-salt water coating painting 10 years warranty (White ） | |
| Ingress protection code | IP67 / IP68 on requests | |
| Mech. impact protection code | IK10 [ 7 J vandal-protected] | |
| Protection class IEC | Safety class I (I) | |
| Corrosion-proof grade | WF2 | |
| Operating Temperature | -40 - +55℃ | |
| Humidity | 10-90% RH | |
| Surge Protection | 10KV/10KA | |
| Labels and Cerifications | ||
| Normative Framework | GB7000、EN60598-1、EN62471、EN61547 | |
| Warranty | 5 years | |
| Applicable Place | Area lighting solutions | |
| Mounting | Mounting bracket adjustable | |
| Dimension | 550*400*63mm | |
| Package Dimension | 590*560*115mm | |
| Maximum Exposed Surface | 0.22㎡ | |
| Control | No | |
| Photosell | No | |
| Motion Sensor | No | |
| Emergency | No | |
| SPD | 10KV/10KA | |
