LCD-405-6500K-LED Marine
LCD-405-6500K-LED Marine
SKU SKU:LCD-FA-405-6500K-LN90
Marine FA floodlight 400W order 2pcs for delight sg.xls
LCDFA -405-LNXXX specification.xlsx
ราคาปกติ
$ 525.00 SGD
ราคาปกติ
$ 577.50 SGD
ราคาโปรโมชัน
$ 525.00 SGD
ราคาต่อหน่วย
/
ต่อ
ค่าจัดส่งที่คำนวณในขั้นตอนการชำระเงิน
ไม่สามารถโหลดความพร้อมในการรับสินค้าด้วยตนเองได้
แบ่งปัน
LED Chip ：SMD 5050 lenses beam angel 30°
CCT: 6500K Lumen output：150-160lm/W
Voltage：90-305VAC / 50/60Hz
Stainless steel # front cover with grid net & bracke/marine anti-salt water coating paint
| Specifiction | data | parameter |
| Power | 400W | |
| Initial luminous flux @4000K |
64,000lm | |
| Initial LED luminaire efficacy | 160lm/W | |
| CRI | ≥70 | |
| Calculated Lumen Maintenance（L79，TM-21@25℃） | ＞100000hours | |
| Color Temperature | 3000/4000/5000K | |
| Distribution | sports/area | |
| Light Distribution Component | polycarbonate microlens optic / PC cover 4mm / stainless steel front 2mm | |
| Light source | anti-high temperature +120℃ LEDs SMD5050/5W/pcs | |
| LED quantity | SMD5050 144 pcs | |
| Input Voltage | AC100-277V 50/60Hz | |
| Driver | CE RoHs SAA UL TUV cUL approved driver | |
| THD | ＜20% | |
| Power Factor | ＞96% | |
| Power-supply Efficiency | ＞90% | |
| Housing | Aluminum Alloy die-casted / stainless steel front | |
| Weight | 13kg | |
| Lens | reflector(Polycarbonate lens for 30deg / 60 deg /9deg etc on requests) | |
| Fixation material bracket | (Stainless steel ) | |
| Anti-UV PC plastic | PC cover 4mm | |
| Finish | 2 layers Mirane grade anti-salt water coating painting 10 years warranty (White ） | |
| Ingress protection code | IP67 / IP68 on requests | |
| Mech. impact protection code | IK10 [ 7 J vandal-protected] | |
| Protection class IEC | Safety class I (I) | |
| Corrosion-proof grade | WF2 | |
| Operating Temperature | -40 - +55℃ | |
| Humidity | 10-90% RH | |
| Surge Protection | 10KV/10KA | |
| Labels and Cerifications | ||
| Normative Framework | GB7000、EN60598-1、EN62471、EN61547 | |
| Warranty | 5 years | |
| Applicable Place | Area lighting solutions | |
| Mounting | Mounting bracket adjustable | |
| Dimension | 550*400*63mm | |
| Package Dimension | 590*560*115mm | |
| Maximum Exposed Surface | 0.22㎡ | |
| Control | No | |
| Photosell | No | |
| Motion Sensor | No | |
| Emergency | No | |
| SPD | 10KV/10KA | |
