Dab Centrifugal Pump 1Hp 230V | Model : K12/200M

1Hp 230V Dab Centrifugal Pump  | Model : K12/200M Features : Single impeller centrifugal pump suitable for domestic, civil, industrial and agricultural installations and for decanting, mixing and irrigating uses. Cast iron pump body and motor support. Technopolymer impeller. Stainless steel driving shaft. Carbon/ceramic mechanical seal. Asynchronous, closed motor, cooled by external ventilation. Built-in thermal and current overload protection and a capacitor permanently on in the single-phase version. For the protection of the three-phase motor it is advisable to use a suitable overload protection complying with the regulations in force. Specifications :  Operating range : from 1,8 to 96 m3/h with headup to 62 metres. Pumped liquid characteristics clean :  free fromsolids or abrasive substances, not viscous, notaggressive, not crystallised, chemically neutral andclose to the characteristics of water Maximum ambient temperature  : +40°C. Protection level : IP 44. Terminal board protection level  : IP 55. Insulation : Class F. Voltage : 220-240 V P1 Max KW : 1.15 P2 (KW/HP) : 0.75 / 1 Weight : 13.7 Kg
